DWC Pipes
DWC Pipes or Double Wall Corrugated Duct Pipes are the ones, which are manufactured from the HDPE Materials and are designed specially to provide the cost effective solutions to the people, who are looking for the replacement of GI, RCC and PVC Pipes for the purpose of laying Fibre Electric Cable networks and Fibre optics. These DWC Pipes are far more superior in terms of technicality and holds several advantages over the other pipes currently in use.
"SHYAM" brand Double Wall Corrugated Duct Pipes are suitable for applications in various fields. DWC Pipes Made from the HDPE Materials, the DWC Pipe are popularly known as the HDPE DWC Pipes. The basic manufacturing materials involved in the production of the HDPE double wall corrugated pipes are the High-density polyethylene, which have the highest life expectancy.
Manufacturing Of HDPE Double Wall Corrugated Pipes
The manufacturing of the HDPE DWC pipes is done in a way such that the products gain maximum longevity and bears the maximum load. The manufacturing process involves the usage of green piping material in order to provide environmental sustainability. Also, the design philosophy of the production of the HDPE DWC Ducts is to provide the suitable properties and the needed safety for the longer time, which allows the most satisfactory working for maximum time and ranging up to 50 years.
We provide DWC HDPE Pipe and DWC HDPE Corrugated Pipe, which is widely used in railways, telecom sector, electric cable ducting, Sewerage disposal and also used for suction purpose. These DWC HDPE Pipe and DWC HDPE Corrugated Pipe are flexible, tough and available as per IS:14930 Part 2:2013 / IS16205 PT.24:2017 for telecom ducting, electrical applications, indoor ventilation etc. and IS:16098 Part-II for Sewerage disposal. Available in varied colors to meet the requirements of clients. We also offer accessories such as coupler and bend, with rubber O ring.
Made with the High-density polyethylene, the talks of the life expectation are a stupid one.Being maintenance free.As of now, the industry is still unorganized, but with the growth of the country and its GDP, the advent of the more organized players in the market, will push the future of the HDPE DWC Duct to the new and higher levels
Availables Size (DWC Pipes) :
| Sizes OD/ID | Length |
|---|---|
| 40 Mm / 32 Mm | 100/200/500 Mtrs. |
| 50 Mm / 38 Mm | 100 Mtrs. |
| 63 Mm / 50 Mm | 6 Mtrs. & 30 Mtrs. |
| 75 Mm / 63 Mm | 6 Mtrs. & 30 Mtrs. |
| 90 Mm / 75 Mm | 6 Mtrs. & 30 Mtrs. |
| 110 Mm / 96 Mm | 6 Mtrs. |
| 120 Mm / 103 Mm | 6 Mtrs. |
| 125 Mm / 107 Mm | 6 Mtrs. |
| 160 Mm / 136 Mm | 6 Mtrs. |
| 180 Mm / 163 Mm | 6 Mtrs. |
| 200 Mm / 175 Mm | 6 Mtrs. |
| 300 Mm / 260 Mm | 6 Mtrs. |
Future Of HDPE Double Wall Corrugated Pipes :
- The future aspects of the DWC Pipe can be judged from the following facts:
- Since, the demand of the underground ducting and piping in on the rise in the country, the future of the economical and sustainable ducting is on the rise.
- The future of the Corrugated pipes of this sort is thus bright, which are highly economical, environmentally safe.
- Offers greater strength and offer better load bearing capability.
- To add, since they are chemically inert, they hold the best chance to be used in more areas, since they are completely safe, even for the longer use (around 5 years or so).
- As of now, the industry is still unorganized, but with the growth of the country and its GDP, the advent of the more organized players in the market, will push the future of the HDPE DWC Duct to the new and higher levels.
